OneChipBook-12 Launches as New FPGA Development Platform with Integrated Display and Mechanical Keyboard

News FPGA Make
Table of Contents

The newly launched OneChipBook-12 by 8086YES! is a compact development platform featuring the Altera Cyclone EP1C12Q FPGA. Designed to resemble a netbook, this device integrates a VGA display, a mechanical keyboard, and multiple ports, catering to developers and enthusiasts alike.

Key Features #

The OneChipBook-12 is equipped with the following specifications:

  • FPGA: Altera Cyclone EP1C12Q240, featuring 12,060 Logic Elements and 239,616 bits of RAM.
  • Memory: 32 MB SDRAM.
  • Storage: An SD card slot compatible with the FAT16 file system.
  • Display: A 1024 x 768 VGA display.
  • Audio: Stereo speakers, an audio output jack, and a volume control knob.
  • USB: One USB Type-A port and a PS/2 port for user input.
  • Mechanical Keyboard: PS/2 keyboard with backlighting, available in two layouts.
  • Expansion: A 50-pin external expansion slot and additional I/O windows for further customization.

Design and Usability #

The OneChipBook-12 showcases a modular design with a mechanical keyboard and integrated speakers. It operates on a lithium battery and features a USB Type-C charging port. The dimensions of the device are 25 x 19 x 3.8 cm when closed, making it portable and easy to handle.

Compatibility and Firmware #

The platform is marketed as a blank FPGA development tool, allowing users to define their own functionalities. While the hardware is reminiscent of contemporary MSX2+ clones, it does not come pre-loaded with any firmware. Users can find a PDF documentation detailing hardware specifications and firmware installation instructions. However, the lack of official guidance on installing MSX firmware may pose a challenge.

Availability #

The OneChipBook-12 is currently available for purchase on Tindie for $215 plus shipping, and can also be found on AliExpress for approximately $235, including shipping costs.

For more information, visit the manufacturer’s page or refer to the detailed specifications linked above.

Source: CNX Software – Embedded Systems News.

↑
